IRFS7537TRLPBF

manufacturer: Infineon Product category: MOSFET Installation style: SMD/SMT Package / box: TO-252-3 Transistor polarity: N-Channel Number of channels: 1 Channel VDS - drain source breakdown voltage: 60 V ID - continuous drain current: 173 A RDS on drain source on resistance: 3.3 mOhms VGS - gate source voltage: - 20 V, + 20 V VGS th gate source threshold voltage: 3.7 V QG gate charge: 142 nC Minimum operating temperature: - 55 C Maximum operating temperature: + 175 C PD power dissipation: 230 W Channel mode: Enhancement Trade name: StrongIRFET to configure: Single Height: 2.3 mm Length: 6.5 mm Transistor type: 1 N-Channel Width: 6.22 mm Trademark: Infineon / IR Forward transconductance - Minimum: 190 S Descent time: 84 ns Product type: MOSFET Rise time: 105 ns Number of factory packages: eight hundred Subcategory: MOSFETs Typical closing delay time: 82 ns Typical on delay time: 15 ns Unit weight: 330 mg
